Send InquiryHTHP Sample Yarn Dyeing Machine
Price 200000.0 INR/ Set
MOQ : 1 Set
HTHP Sample Yarn Dyeing Machine Specification
- Fabric Type
- Yarn
- Voltage
- 220V / 380V
- Pump Type
- Centrifugal Pump
- Control Type
- PLC & Digital Touch Panel
- Dimension (L*W*H)
- 1100 mm x 800 mm x 1450 mm
- Applicable Material
- Cotton, Polyester, Blends, Silk, Wool
- Manufacturing Year
- 2 Months
- Weight
- Approx. 150 kg
- Usage & Applications
- Laboratory sample dyeing, R&D, Textile dyeing sample preparation
- Temperature Range
- Up to 140C
- Machine Type
- High Temperature High Pressure (HTHP) Sample Yarn Dyeing
- Features
- Uniform dyeing, Energy efficient, Corrosion-resistant body, Automatic timer
- Capacity
- Up to 500g yarn per batch
- Condition
- New
- Power
- 3 kW
- Type
- HTHP Yarn Dyeing Machine
- Speed
- Variable speed
- Volume
- 10-15 Liters
- No Of Chamber
- Single Chamber
- Control Accuracy
- 1C
- Pressure Range
- Up to 4.5 bar
- Water Inlet/Outlet
- 1/2 inch BSP Threaded Coupling
- Safety Features
- Pressure Relief Valve, Over-temperature Alarm, Interlock System
- Finish
- Mirror Polished Interior
- Dosing System
- Manual or Automatic Dosing
- Heating Method
- Electrical / Steam Heating
- Insulation
- Mineral Wool Insulated Body
- Power Supply
- Single/Three Phase Optional
- Sample Holder
- Multiple Spindle Arrangement
- Material of Construction
- Stainless Steel 316/304
HTHP Sample Yarn Dyeing Machine Trade Information
- Minimum Order Quantity
- 1 Set
- Payment Terms
- Cash Advance (CA)
- Supply Ability
- 2 Sets Per Month
- Delivery Time
- 2 Week
- Sample Available
- No
- Packaging Details
- As per Customer Requirement.
- Main Domestic Market
- South India
About HTHP Sample Yarn Dyeing Machine
HTHP Sample Yarn Dyeing MachineThe HTHP Sample Yarn Dyeing Machine is a specialized laboratory-scale dyeing unit designed for high-precision dyeing of yarn samples under high temperature and high pressure conditions. This machine is ideal for research and development, quality control, and small-batch sample dyeing in textile industries.
Key Features:
-
High Temperature & Pressure Operation:
Operates up to 140C and 5 bar pressure, enabling dyeing with disperse and other synthetic dyes that require elevated conditions. -
Sample Capacity:
Typically handles 500g to 2Kg yarn samples (varies by model), suitable for lab-scale sampling and color matching. -
Material Compatibility:
Suitable for dyeing various yarn types including cotton, polyester, wool, nylon, acrylic, and blends. -
Even Dyeing Results:
Equipped with a reversible pump system that ensures uniform dye liquor circulation, providing excellent color consistency and repeatability. -
Energy Efficient:
Features efficient heating systems (usually via electric or steam heating). -
Programmable Controls:
Integrated with digital controllers or PLC systems for setting and monitoring temperature, time, pressure, and dyeing cycles. -
Safety Features:
Comes with automatic pressure release, over-temperature protection, and locking mechanisms for safe operation.
Applications:
-
Color shade development and matching
-
R&D for new dye formulations and yarn materials
-
Quality assurance and sample testing in textile mills and dyeing units
Advanced Construction and Materials
Utilizing stainless steel 316/304, this HTHP machine guarantees resistance to corrosion and thermal stress while maintaining durability. The mirror-polished interior enhances ease of cleaning and prevents contamination, which is essential for precise laboratory dyeing tasks. Mineral wool insulation ensures minimal heat loss, boosting overall energy efficiency.
Intuitive and Accurate Control Systems
Equipped with a PLC programmable logic controller and a digital touch panel, the machine offers precise management with 1C accuracy. Combined with the automatic timer and strong safety interlocks, operators can achieve consistent reproducibility in each dyeing process, ideal for R&D and sample development environments.
Multipurpose Usage and Application
Suitable for a variety of yarn materials, this versatile dyeing machine is frequently used in textile laboratories, R&D centers, and sample preparation units. With a batch capacity of up to 500g and compatibility for cotton, polyester, blends, silk, and wool, it streamlines the preparation of sample lots under high temperature and pressure conditions.
FAQ's of HTHP Sample Yarn Dyeing Machine:
Q: How does the HTHP Sample Yarn Dyeing Machine ensure uniform dyeing results?
A: Uniform dyeing is achieved through its centrifugal pump design, variable speed control, and a mirror-polished interior that enhances bath circulation. The precise PLC & touch panel control further ensures consistent temperature and pressure during the dyeing process.Q: What materials can be dyed using this machine?
A: This machine is suitable for dyeing cotton, polyester, blends, silk, and wool yarns, making it ideal for diverse sample preparations in textile R&D and laboratory settings.Q: How is operator safety maintained during operation?
A: Safety is prioritized with a pressure relief valve, over-temperature alarm, interlock system, and mineral wool insulated body, all of which help prevent over-pressurization, overheating, and accidental operation.Q: What are the advantages of its stainless steel construction?
A: The stainless steel 316/304 construction offers high corrosion resistance, durability at elevated temperatures and pressures, and a hygienic mirror finish suitable for consistent laboratory environments.Q: Where is this machine typically used?
A: This dyeing machine is commonly used in textile industry laboratories, research and development departments, and sample dyeing workshops for accurate and efficient small-batch processing.Q: When is it recommended to use manual versus automatic dosing?
A: Manual dosing is suitable for experimental or highly customized batches, while automatic dosing is preferred for standardized procedures requiring precise and repeatable addition of chemicals or dyestuffs.Q: What benefits does the mineral wool insulation provide?
A: Mineral wool insulation effectively minimizes heat loss, enhances energy efficiency, and contributes to maintaining stable internal temperatures, which is essential for reproducible dyeing results.
